Part Number

53039880005

Previous Version

5303-988-0005, 5303 988 0005, 53039880013

OE number

058145703LX, 058145703LV, 058145703E, 058145703C, 058145703H, 058145703L, 058145703D

Year

1996-2012

Description

Audi Volkswagen

Manufacturer Part Number

53039700005, 5303-970-0005, 53039700013

CHRA

53037100502 (5303-710-0502) Available

Turbo Model

K03-2072GAA4.82KCAXKM, KO3-005

Engine

1,8-5V langs/along, AEB, AJL

Displacement

1.8L, 1781 ccm

KW

110/132/150 HP

RPM Max

5500

Fuel

Gasoline

Angle α (compressor housing)

160 dge

Angle β (turbine housing)

150 dge

Bearing Housing

53041500006/53041500017

Turbine Wheel

53031205029/53031205014

Comp. Wheel

53041232007/53041232018

Back plate

53041515702

Heat shield Number

5303652000

Repair Kit

53037110000

Turbine Housing

53031009019

Compressor Cover

53041015003

Turbine Housing AR

4

Actuator

58251104028

Settings Waste gate (pressure)

0.370 bar

Settings Waste gate (lift shaft)

4.00 mm

Gasket (turbine inlet)

210337 (METAL & PAPER GASKET)

Gasket (turbine outlet)

210242 (STEEL)

Gasket (oil outlet)

210310

Manufacturer

WUXI EbayTurbo of China

Condition

Brand new
