Part Number

53279886502

Previous Version

5327-988-6502, 5327 988 6502

OE number

0040966099, 0040967499, 0040967599, 0040968099, 0040966299, 0040966199, 0040966399, 40966199, 40966099, 40966299, 40966399, 40968099, 40967499, 40967599

Year

Dec-90

Description

Truck/Bus/Industrial Engine

Manufacturer Part Number

5327-970-6507, 5327-970-6502, 5327-970-6511, 5327-988-6508, 5327-970-6507, 5327-970-6502, 5327-970-6511, 5327-988-6508

CHRA

53277100109 (5327-710-0109)

Turbo Model

K27-3465MXEAA18.20RNADD

Engine

OM422LA, OM442LA-Euro 1, 0M442LA-E2 CLAAS

Displacement

14.62L, 14620 ccm, V8 Cylinders

KW

429/496

RPM Max

1900/2100

Fuel

Diesel

Angle α (compressor housing)

0/95 dge

Bearing Housing

53271500016 (53271500012, 312836, 313119)(1301027455, 203140004)

Turbine Wheel

53271205074 (53271202127, 53271205003)(Ind. 66. mm, Exd. 76.1 mm, 12 Blades)(201110012)

Comp. Wheel

53291232208 (Ind. 56.85 mm, Exd. 87.03 mm, Trm 3.50, 6+6 Blades, Superback)(202090017)

Back plate

53271516818 (53271516714)

Heat shield Number

53271652005 (312837)(1301027342, 206270003)

Repair Kit

53277110070 (53267110051)

Turbine Housing

53271018523 (53271018512)

Compressor Cover

53291015035

Turbine Housing AR

18

Gasket (turbine inlet)

409039-0000 (210022-0000, 409039-0000, 2405022) (Inox Steel)

Gasket (turbine outlet)

210274 (Stainless Steel)

Gasket oil inlet

210023 (409036-0000, 210023-0000, 55739, 147837)(Paper)

Gasket (oil outlet)

210060 (409267-0003, 409267-0002, 210060-0000, 51914, 148062, 311585)(Paper)

NOTE

Intercooler

Replaced by

53279886507, 466214-0028, 3580178

Manufacturer

WUXI EbayTurbo of China

Condition

Brand new
