2006- Volkswagen Golf V TDI, Jetta TDI, Passat TDI, Touran TDI BKD 2.0 TDI 4 Valve Euro-4
-
2006- Audi A3 TDI 2.0L, 4 Valve
-
2006- Skoda Octavia TDI, Superb TDI AZV Euro-4
-
2006- Seat Altea TDI, Leon TDI AZV Euro-4
2004-10 Audi Volkswagen GT1749V (S2) Turbo 724930-0009
|
Part Number |
724930-5009S |
|
Previous Version |
724930-0002, 724930-0004, 724930-0006, 724930-0009, 724930-5006S, 724930-5008S |
|
OE number |
03G253014H, 038253016F, 038253016E, 038253019F, 038253016FV115, 038253016FV510, 038253016FV500, 03G253019A, 03G253019AV, 03G253019AX, 03G253019AV550, 03G253010J, 03G253010JX, 03G253010JV, 9102117007, 03G253019HV100, 03G253014J, 03G253019A |
|
Year |
Oct-04 |
|
Description |
Audi, Volkswagen, Skoda, Seat |
|
CHRA |
703890-0127 (703890-0034, 703890-0060, 703890-0148, 703890-0123, 703890-0160)(1102015935) |
|
Turbo Model |
GTA1749MV(S2), GTA1749MV, GT1749MV, GT1749V (S2) |
|
Engine Manufacturer |
VW |
|
Engine Code |
BKD AZV Euro-4 |
|
Displacement |
2.0L, 4 Valve 1968 ccm, 4 Cylinders |
|
KW |
138 |
|
RPM Max |
4000 |
|
Fuel |
Diesel |
|
Bearing Housing |
722282-0013 (703880-0002, 722282-0060, 722282-0062, 433145-0005) (1102017458, 1102017450) |
|
Turbine Wheel |
434533-0035 (433257-0010, 434533-0007, 434533-0009, 434533-0059, 721161-0004)(Ind. 36. mm, Exd. 43.1 mm, 9 Blades) (1102017441, 1102017438) |
|
Comp. Wheel |
702489-0009 (702489-0002, 702489-0006)(Ind. 49. mm, Exd. 34.7 mm, Trm 50, Extended back disc type 6 blades) (1102015401) |
|
Back plate |
703682-0045 (700593-0006, 703682-0023) (1102015300) |
|
Heat shield Number |
433112-0001 (1102015342) |
|
Repair Kit |
732252-0001 (1102015781, 1102015756) |
|
Thrust Kit |
732248-0003/732252-0001 |
|
Nozzle Ring |
704013-0001 (1102017830) |
|
Turbine Housing AR |
VNT2 |
|
Actuator |
1102117381 |
|
Gasket Kit |
1900100311 |
|
Gasket (turbine inlet) |
210821 (Inox Steel) |
|
Gasket (oil outlet) |
210243 |
|
Gasket (actuator EGR) |
210313 (Stainless Steel) |
|
Manufacturer |
WUXI EbayTurbo |
|
Condition |
Brand new |
