Part Number

709838-5005S

Previous Version

709838-0001, 709838-0003, 709838-0004, 709838-0005, 709838-5

OE number

6120960399, A6120960399

Year

Apr-00

Description

Commercial Sprinter 216, 316, 416, 616

CHRA

703891-0064 (703891-0032, 703891-5064S)(1102022901)

Turbo Model

GT2256V

Engine

OM612 D5S

Engine Manufacturer

Mercedes Benz

Displacement

2.7L, 2688 ccm, 5 Cylinders

KW

125 HP

Bearing Housing

722282-0020 (1102022450)

Turbine Wheel

434882-0005 (434882-0010)(Ind. 50. mm, Exd. 42.7 mm, 9 Blades)(1102022435)

Comp. Wheel

701374-0003 (Ind. 39.6 mm, Exd. 56. mm, 6+6 Blades, Superback)

Back plate

701335-0005 (434822-0002)(104010030)(1102025300)

Heat shield Number

443768-0003 (702486-0011)(1102015340)

Repair Kit

732252-0001 (1102015756)

Nozzle Ring Assemblies

707050-0013/717506-0025

Turbine Housing

708960-0001

Compressor Cover

704519-0001

Turbine Housing AR

VNT2

Actuator

434855-0009 (2061016341)

Settings waste gate (pressure)

0.560-0.600 bar

Settings Waste gate (lift shaft)

10.5-12.5 mm

Gasket (turbine inlet)

210378 (Inox Steel)

Gasket (oil outlet)

210243 (34336-04100, paper)

Manufacturer

WUXI EbayTurbo

Condition

Brand new
