Part Number

49189-01800

OE Number

9172180, 55559825

Year

Feb-98

Description

Saab 9-3; 9-5 Aero; Viggen

CHRA

49189-08525

Turbo Model

TD04HL-15T-6

Power

250 BHP

Engine

B253R

Engine Manufacturer

Saab

Displacement

2.3L, 2290 ccm, 4 Cylinders

Fuel

Gasoline

Bearing Housing

49189-26050 (49189-26170, 49189-26020)(Water-cooled)(1401404462)

Turbine Wheel

49189-30100 (Ind. 52. mm, Exd. 45.6 mm, 12 Blades) (1401404438)

Comp. Wheel

49189-43500 (49189-00015, 49377-00017)(Ind. 40.67 mm, Exd. 56. mm, Trm 52, 6+6 Blades, Flat back)

Back plate

49135-15405 (49135-00044, 49173-22500) (1401635300, 1800015016)

Heat shield Number

49183-19300

Repair Kit

49189-84000 (2455154)

Turbine Housing

49189-16401

Turbine Housing AR

6

Actuator

49189-18650 (49189-18651)

Gasket (turbine inlet)

210224 (Stainless steel)

Gasket (oil outlet)

210243 (Paper)

Replaces

452204-0005

Manufacturer

WUXI TurboMaker of China

Condition

Brand New
