Part Number

53049880022

Previous Version

5304-988-0022, 5304 988 0022

OE number

06A145704P, 06A145704PX, 06A145704PV

Year

Dec-99

Description

Audi TT, S3

Manufacturer Part Number

53049700022, 5304-970-0022, 5304 970 0022

CHRA

53047100507 (5304-710-0507, 1302004907)

Turbo Model

K04-2275ECD5.82KCAXH

Displacement

1.8L, 1781 ccm, V5 quer, transverse

Engine

AMK, AMK APX

KW

154/210 HP

RPM Max

5900

Fuel

Gas

Angle α (compressor housing)

305 dge

Angle β (turbine housing)

190 dge

Bearing housing (water-cooled)

53041500015/53041500009/53041500006/53041500017

Turbine Wheel

53041205015/53041205010 (Ind. 50. mm, Exd. 42. mm, 12 Blades)

Comp. Wheel(milled titanium)

53041232015/53041232013/53041232203(Ind. 41.86 mm, Exd. 56.06 mm, 4+4)

Back plate

53041515708 (1302003306)

Heat Shield

53041652000 (1302003341)

Repair Kit

53037110000 (1302003752)

Turbine Housing

53041008003

Compressor Cover

53041015030

Turbine Housing AR

5

Actuator

58251104082

Settings Waste gate (pressure)

0.50 bar

Settings Waste gate (lift shaft)

5.50 mm

Gasket (turbine inlet)

210646 (INOX Steel)

Gasket (turbine outlet)

210676 (INOX Steel)

Gasket (oil outlet)

210317 (Paper)

Manufacturer

WUXI EbayTurbo of China

Condition

Brand new

Interchangeable with 53049880020
